Fluke 190-104/S Scopemeter Repair

Fluke Scopemeter Repair & Calibration
(1 customer review)

$245.00

Precision Fluke 190-104/S repair with traceable calibration documentation. Service covers input channel restoration, display replacement, battery rebuild, trigger circuit repair, and input isolation verification. Nationwide service — ship from anywhere in the US.

Category: Tags: , , , , , , , , ,

Description

Fluke 190-104/S ScopeMeter Repair

The Fluke 190-104/S is a rugged, isolated handheld ScopeMeter — a 100 MHz four-channel portable scope (190 II series; the /S adds the SCC accessory kit) with independently floating, isolated inputs for industrial and field troubleshooting on power, motor-drive, and electronic systems. As a field-carried instrument, its faults concentrate in the isolated input front-ends, the display, and the battery/power section.

FlukeMeterRepair.com repairs and calibrates the Fluke 190-104/S for industrial maintenance and field-service teams.

Common Fluke 190-104/S problems we fix

  • Input-channel restoration — a dead, noisy, or inaccurate channel among the four from isolated front-end damage, repaired and recalibrated.
  • Display replacement — a blank, dim, or cracked display, replaced.
  • Battery rebuild — won’t power on or hold a charge, the battery pack and power section serviced.
  • Isolated-input breakdown — damage to the floating input isolation, repaired.
  • Input or connector faults.

FAQs

My 190-104/S display or a channel is failing — fixable? Yes. Display, battery, and isolated-input faults are repairable, then the channels are recalibrated so measurements are accurate, with a NIST-traceable certificate.

Are all four channels recalibrated? Yes — each channel is checked against our standards.

Every repair includes NIST-traceable calibration and a 90-day parts-and-labor warranty. Email us or request service.

Brand

Fluke Scopemeter Repair

Fluke ScopeMeter products combine the functionality of an oscilloscope, a digital multimeter (DMM), and data recorder into portable handheld devices. They are designed for troubleshooting and diagnosing electrical and electronic systems in industrial, field service, and laboratory environments. Here are some key Fluke ScopeMeter products and their functionalities:
  1. Fluke 120 Series Handheld Oscilloscopes:
    • Functionality: Combines oscilloscope, multimeter, and recorder capabilities in a single portable device.
    • Features: Measures and displays voltage, current, frequency, and waveform characteristics. Can capture and analyze transient events and signal anomalies.
    • Applications: Suitable for field service technicians and maintenance professionals for troubleshooting electrical systems, motors, control circuits, and industrial automation.
  2. Fluke 190 Series II Portable Oscilloscopes:
    • Functionality: High-performance portable oscilloscopes with advanced measurement capabilities.
    • Features: Offers bandwidths up to 500 MHz, fast sampling rates, deep memory, and flexible triggering options. Provides detailed waveform analysis and trend recording.
    • Applications: Used in industrial, automotive, and aerospace applications for diagnosing complex electrical and electronic systems, including control systems and communications networks.
  3. Fluke 123, 124, and 125 Industrial ScopeMeters:
    • Functionality: Robust handheld oscilloscopes designed for rugged industrial environments.
    • Features: Offers dual input channels, up to 40 MHz bandwidth, and real-time sampling rates. Includes DMM capabilities for voltage, current, resistance, and continuity measurements.
    • Applications: Ideal for maintenance technicians and engineers working on machinery, process control systems, and power distribution systems where portability and durability are crucial.
  4. Fluke 190-204/S Portable ScopeMeter:
    • Functionality: Four-channel portable oscilloscope with DMM capabilities.
    • Features: Offers bandwidths up to 200 MHz, deep memory, and advanced triggering options. Provides simultaneous viewing of multiple signals and real-time data recording.
    • Applications: Used in complex industrial environments for troubleshooting electrical systems, analyzing control signals, and verifying performance of electronic components and circuits.
  5. Fluke ScopeMeter 120B Series:
    • Functionality: Compact and rugged handheld oscilloscopes with DMM functions.
    • Features: Offers bandwidths up to 100 MHz, dual input channels, and fast sampling rates. Includes automatic measurements, waveform recording, and trend plotting.
    • Applications: Suitable for service and maintenance tasks in automotive, HVAC, and process industries where space and portability are critical.
Fluke Scopemeter Repair & Calibration

1 review for Fluke 190-104/S Scopemeter Repair

  1. Mitchell Adams –

    Our Fluke 190-104 stopped powering up, tried a new charger, then purchased a new battery with no success. Sent our Fluke scopemeter in for evaluation and JT was very on top of correspondence both vie phone and email. Very impressed attention to detail. The Fluke scopemeter was repaired, calibrated to ISO-17025 and returned within a week.
