Fluke 199C/003 Scopemeter Repair

Fluke Scopemeter Repair & Calibration

$245.00

Authorized Fluke 199C/003 repair, calibration, and restoration services. Our technicians specialize in input channel restoration, display replacement, battery rebuild, trigger circuit repair, and input isolation verification. Nationwide service — ship from anywhere in the US.

Category: Tags: , , , , , , , , ,

Description

Fluke 199C/003 ScopeMeter Repair

The Fluke 199C is a rugged handheld ScopeMeter (199C/003 kit) — a 200 MHz two-channel portable scope-plus-meter (190C Color series), the top of the 190C line, with isolated inputs for industrial field troubleshooting. As a field-carried instrument, its faults concentrate in the isolated input front-ends, the color display, the trigger system, and the battery.

FlukeMeterRepair.com repairs and calibrates the Fluke 199C for industrial maintenance and field-service teams.

Common Fluke 199C/003 problems we fix

  • Input-channel restoration — a dead, noisy, or inaccurate channel from isolated front-end damage, repaired and recalibrated.
  • Color-display replacement — a blank, dim, or cracked display, replaced.
  • Battery rebuild — won’t power on or hold a charge, the battery pack and power section serviced.
  • Trigger-system faults — unstable or wrong triggering, corrected.
  • Input or connector faults.

FAQs

My 199C display or a channel is failing — fixable? Yes. Display, battery, and isolated-input faults are repairable, then the channels are recalibrated so measurements are accurate, with a NIST-traceable certificate.

Are the inputs recalibrated? Yes — both channels are checked against our standards.

Every repair includes NIST-traceable calibration and a 90-day parts-and-labor warranty. Email us or request service.

Brand

Fluke Scopemeter Repair

Fluke ScopeMeter products combine the functionality of an oscilloscope, a digital multimeter (DMM), and data recorder into portable handheld devices. They are designed for troubleshooting and diagnosing electrical and electronic systems in industrial, field service, and laboratory environments. Here are some key Fluke ScopeMeter products and their functionalities:
  1. Fluke 120 Series Handheld Oscilloscopes:
    • Functionality: Combines oscilloscope, multimeter, and recorder capabilities in a single portable device.
    • Features: Measures and displays voltage, current, frequency, and waveform characteristics. Can capture and analyze transient events and signal anomalies.
    • Applications: Suitable for field service technicians and maintenance professionals for troubleshooting electrical systems, motors, control circuits, and industrial automation.
  2. Fluke 190 Series II Portable Oscilloscopes:
    • Functionality: High-performance portable oscilloscopes with advanced measurement capabilities.
    • Features: Offers bandwidths up to 500 MHz, fast sampling rates, deep memory, and flexible triggering options. Provides detailed waveform analysis and trend recording.
    • Applications: Used in industrial, automotive, and aerospace applications for diagnosing complex electrical and electronic systems, including control systems and communications networks.
  3. Fluke 123, 124, and 125 Industrial ScopeMeters:
    • Functionality: Robust handheld oscilloscopes designed for rugged industrial environments.
    • Features: Offers dual input channels, up to 40 MHz bandwidth, and real-time sampling rates. Includes DMM capabilities for voltage, current, resistance, and continuity measurements.
    • Applications: Ideal for maintenance technicians and engineers working on machinery, process control systems, and power distribution systems where portability and durability are crucial.
  4. Fluke 190-204/S Portable ScopeMeter:
    • Functionality: Four-channel portable oscilloscope with DMM capabilities.
    • Features: Offers bandwidths up to 200 MHz, deep memory, and advanced triggering options. Provides simultaneous viewing of multiple signals and real-time data recording.
    • Applications: Used in complex industrial environments for troubleshooting electrical systems, analyzing control signals, and verifying performance of electronic components and circuits.
  5. Fluke ScopeMeter 120B Series:
    • Functionality: Compact and rugged handheld oscilloscopes with DMM functions.
    • Features: Offers bandwidths up to 100 MHz, dual input channels, and fast sampling rates. Includes automatic measurements, waveform recording, and trend plotting.
    • Applications: Suitable for service and maintenance tasks in automotive, HVAC, and process industries where space and portability are critical.
Fluke Scopemeter Repair & Calibration
